Case 116: Endodontic and Fiber Post placement on upper right canine

Assalamualaikum Wr Wb.. Good Morning!!

welcome back to SekilasKonservasiGigi.Com, a full story of my mini series updated from my social media such as instagramfacebookgoogle plus, and also twitter. Sometimes, I also updated my cases at Line or Linkedin. 🙂 this topic will focus only on conservative dentistry cases such as restorative dentistry and endodontic or root canal treatment.


Endodontic and Fiber Post placement on upper right canine

Long time no post case with fiber post.
This case will emphasize on the length of fiber post in post endodonticallh treated tooth.
The post should be long enough to meet the aforementioned biomechanical demands without jeopardizing root integrity. The standard parameters for post placement in a tooth with normal periodontal support are:
1. In case of non adhesive cementation (metal post only):
a. 2/3 the length of the canal
b. A radicular extension at least equal to the coronal length of the core
c. One half the bone-supported length of the core
2. In case of adhesive cementation (fiber post)
a. 1/3 to 1/2 the length of the canal, maximum
b. A radicular extension about the coronal length of the core.

Goodacre CJ. Spolnik KJ: the prosthodontic management of endodontically treated teet: a literature review. II. Maintaining the apical seal. J. Prosthodont. 4:51. 1995

Dietschi D. Duc O, Krejci I, Sadan A: Biomechanical consideration for the restoration of endodontically treated teeth: a systematic review of the literature. Part 1. Quintessence int. 38. 733-743. 2007.


This case protocols: Shaping was done with Mtwo files (VDW) with clockwise reciprocal motion (imate2C endomotor from Denjoy). Cleaning with sodium hypochlorite 5,24% (generic), EDTA 18% sol (ultradent), CVC guttapercha with resin based sealer. Fiberpost cemented with resin cement (relyx u200 – 3M), and core build up with bulkfill composite (filtek bulkfill – 3M). Xray evaluation with vistaray 7.1 sensor (durr) showed intact marginal integrity and homogeneous body.

Yup, that’s for my 116th story in SekilasKonservasiGigi.Com, For more stories please visit CeritaPasienRio.Com or browse my fb at and don’t forget to click the follow botton on your rigth side to get the latest updates from my site.. see you on my next dental story..

thank You Very Much,

keep UP the GOOD WORK!!

keep on Sharing,

with love from Jakarta, Indonesia

Wassalammualaikum Wr Wb..

-drg. Rio Suryantoro, Sp.KG-

(Conservative Dentistry Specialist / Endodontist)
